Details
The energy storage battery Containers are built on a modular structure. We can customize them to match the capacity and power requirements of the client's needs. The energy storage systems for batteries are built on the standard container for sea frei
Description
| Technical Specifications | |
| Battery Type | LiFePO4(LFP) |
| Nominal Voltage(V) | 51.2V |
| Nominal Energy(KWH) | 5.12KWH |
| Design Capacity | 100AH |
| Design Years | 15 Years |
| Product Size | |
| Size | 600*510*173mm |
| Weight | 51kg |
| Technical Parameter | |
| Cycle Life | ≥6000 80% DOD |
| Operating Voltage Range | 40V-58.4V |
| Charging Voltage | DC 58.4V |
| Charge/Discharge Current(A) | Same Port 100A |
| Internal Resistance | ≤30mΩ |
| BMS Parameters | |
| Self-Consumption | ≤2W |
| Rated Voltage | 51.2V |
| Balance Current | 30-65(MA) |
| Communication Method | CAN/RS485/RS232 |
| Information Storage | 500 Strip |
| Limiting | 10/20A(Optional) |
| Ambient Temperature | |
| Operating Temperature | -10°C-50°C |
| Storage Temperature | 10°C-50°C |
| Humidity | 15%-75% |
| Warranty | |
| Warranty | 5 Years |
