12.3kWh-288kWh Lithium Battery For Energy Storage Systems Container

  • ESS Container
  • ESS Container

Details

1. Platform Design for Energy, Medium and Power Solutions 2. 0.5C to 2C options available for Frequency regulation, Peak Shaving. Energy Reserve, etc 3. The Highest Energy density for LFP Energy Solution to optimize footprint and BOP cost

Details

Description

12.3kWh-288kWh Lithium Battery For Energy Storage Systems Container





Features of Module & Rack Design

1. Platform Design for Energy, Medium and Power Solutions
2. 0.5C to 2C options available for Frequency regulation, Peak Shaving. Energy Reserve, etc
3. The Highest Energy density for LFP Energy Solution to optimize footprint and BOP cost
4. Passive & Active Thermal Ventilation System, Designed in both Module & Rack
5. Particular Considering for Containerized solution with proper aisle space
6. The Highest Lifetime Performance for Energy Storage System
7. Tested and Listed to UL and IEC Standard for Safety

NESP Container Solution


NESP Module & Rack Specification


Item Module Rack Type 1 Rack Type 2 Rack Type 3
Type No.   76.8NESP160 76880135 768S0160 76880184
Cell Capacity Ah 160 160 160 160
Energy kWh 12.3 135 160 1S4
Nominal Volt V 76.8 844.8 998.4 1152.0
Minimum Volt V 67.2 739.2 873.6 1008.0
Maximum Volt V 86.4 950.4 1123.2 1296.0
Dimension mm 400*884*265 500*938*1860 (2 pcs) 500*938*2130 (2 pcs) 500*938*2400 (2 pcs)
(W x D x H)
Weight kg 129 1644 1947 2250


Item Module Rack Type 1 Rack Type 2 Rack Type 3
Type No.   76.8NESP200 768100169 768100200 768100230
Cell Capacity Ah 200 200 200 200
Energy kWh 154 169 200 230
Nominal Volt V 76.8 844 8 998 4 1152.0
Minimum Volt V 67.2 739.2 8736 1008.0
Maximum Volt V 864 9504 1123.2 1296.0
Dimension mm 400*884*265 500*938*1860 (2 pcs) 500*938*2130 (2 pcs) 500*938*2400 (2 pcs)
(W x D x H)
Weight kg 134 1699 2012 2325


Item Module Rack Type 1 Rack Type 2 Rack Type 3
Type No.   768NESP250 768125211 768125250 768125288
Cell Capacity Ah 250 250 250 250
Energy kWh 19.2 211 250 288
Nominal Volt V 76.8 844.8 998.4 1152.0
Minimum Volt V 67.2 739.2 873.6 1008.0
Maximum Volt V 86.4 9&0.4 1123.2 1296.0
Dimension mm 400*884*265 500*938*1860 (2 pcs) 500*938*2130 (2 pcs) 500*938*2400 (2 pcs)
(W x D x H)
Weight kg 147 1842 2181 2520
